2021 Canyon Ultimate CF SL 8 Disc Aero

Frame

Canyon Ultimate CF SL Disc, Road race bike frame with design and geometry proven at the highest levels of competition., Material: carbon, Axle dimensions: 12 x 142 mm, Brake mount: flat mount, Weight: 860 g

BB Standard: BB86/BB92, Press Fit

Colors: True Grey; Light Blue

Fork

Canyon FK0051 CF Disc

Bottom Bracket

Shimano Pressfit BB72, Pressfit BB86 road standard, compatible with 24 mm axles featuring Hollowtech 2 technology. Weight: 69 g

Saddle

Selle Italia SLR Boost Superflow S manganese, Saddle with modern short-nose design and unisex ergonomics. Width: 130 mm (S), rail material: manganese, weight: 208 g

Seatpost

Canyon S13 VCLS CF, Material: Carbon, Setback: 15 - 35 mm, Technology: VCLS, Weight: 220 g

Type: Rigid

Pedals

None included

Groupset

Rear Derailleur

Shimano Ultegra Di2 R8050 SS, 11-speed, short cage design, max. cassette size: 30T, Shadow Shifting technology. Weight: 240 g

Front Derailleur

Shimano Ultegra Di2 R8050, 2x11-speed, with automatic trimming adjust, braze-on mount. Weight: 130g

Crank

Shimano Ultegra R8000, Gearing ratio: 52/36, with Hollowtech 2 technology for reduced weight. Weight: 690 g | 4iiii Precision Ultegra R8000 Power Meter, Number of chainrings: 2

Power Meter

Shimano Ultegra R8000, Gearing ratio: 52/36, with Hollowtech 2 technology for reduced weight. Weight: 690 g | 4iiii Precision Ultegra R8000 Power Meter, Number of chainrings: 2

Shifters

Shimano Ultegra Di2 R8070 2s, Weight: 180 g | Shimano Ultegra Di2 R8070 11s, Weight: 180 g

Cassette

Shimano Ultegra R8000 11-30 11s, Advanced mix of aluminium, carbon and steel reduces weight and increases durability. Gear range: 11-30T. Weight: 269 g

Chain

Shimano HG701 11-speed, High-grade chain with premium SIL-TEC treatment on roller link plate and pin link plate for increased durability and efficiency.

Brakes

Shimano Ultegra Di2 R8070 2s, Weight: 180 g | Shimano Ultegra Di2 R8070 11s, Weight: 180 g

Type: Shimano Ultegra Hydraulic Disc

Brake Levers

Shimano Ultegra Di2 R8070 2s, Weight: 180 g | Shimano Ultegra Di2 R8070 11s, Weight: 180 g

Wheels

Rims

DT Swiss ARC 1400 Dicut db, Front wheel with Aero+ technology for stability and low drag. Tubeless-ready. Rim depth: 50 mm, inner width: 20 mm, weight: 716 g | DT Swiss ARC 1400 Dicut db, Rotor Mount: Center Lock

Tires

Continental Grand Prix 5000 25mm, High-performance foldable clincher tyre made from high-grade BlackChili compound, with Vectran breaker for enhanced puncture protection. Tanwall sidewall. TPI: 330, weight: 225 g

Disc Rotors

Shimano MT800, Light, high-grade centrelock brake rotor. Featuring Ice Freeza technology for superior heat management, creating consistent braking performance and increasing brake pad life. Weight: 133 g.
